Tractor-mounted Water Well Drilling Rig

A drilling rig for finding water sources

Category：

Water well drilling rig

Keywords：

Well drilling rig

Tel：

+8615376211860

Related Products

CZ800 Water Well Drilling Rig

Features of CZ800 Water Well Drilling Rig:

Features of 800m deepwater drilling rig for water and gas:

1. Equipped with 153KW Cummins 6-cylinder turbocharged engine, strong power and long service life; 2. Patented composite boom, double cylinder lifting, and reinforced tower;

3. (Imported oil pump from Italy) 3-way oil pump, equipped with foam pump, winch, multi-function generator, front leg swing arm cylinder;

4. Each drilling rig is equipped with a baffle on the main arm to protect the oil cylinder;

5. Large drilling diameter, deep drilling, and fast propulsion speed

6. Drilling rig chassis: reinforced steel crawler, large chassis, sturdy and durable, heavy load, wide chain plate, and large tonnage.

7. Parallel transmission design, sufficient power, reasonable distribution, unique hydraulic system design, simple maintenance, and low cost.

8. Independent heat dissipation dual system adopts hydraulic oil temperature cooling and is equipped with traditional air cooling. Long engine life 9. Equipped with dual systems: 1. Air power system with air compressor 2. Mud pump system with mud pump

10. Chassis uses 6*4 Dongfeng Cummins engine

Product Description

The weight (T)

Drill pipe diameter (mm)

Φ102 Φ108 Φ114

The hole diameter (mm)

140-400

Drill pipe length (m)

1.5m 2.0m 3.0m 6.0m

Drilling depth (m)

800

Rig lifting force (T)
